Padgett's Manufacturer Drop Brackets

Are available in the following configurations:

  • 1-1/4” and 4-1/4” standard drop
  • 5/8” thru 1-1/4” drop slot
  • 4”, 6” & 8” bolt centers for mounting
  • Painted or optional galvanized plating
  • 1-1/4” thru 6” upright types
  • More belt side clearance (J type)
  • Open and closed mounting holes
  • Standard & heavy duty available
  • Custom engineered brackets

Padgett's Ceramic Guide Rollers

Offer the following:

  • Standard 2-1/4” tubing & 13/16” shaft
  • Threaded or non-threaded shafting
  • Smooth concave design
  • Field installation of ceramic disc
  • Retrofits on 2” thru 2-3/8” tubes
  • Height adjustable
  • 5” or 6” diameter ceramics
  • Stainless seals and sealed bearings
  • Shaft or bracket mounting types
  • Superior service life

Ceramic Belt Wiper (the answer to your belt cleaning problem Important aspects of the Ceramic

Belt Wiper are:

  • Low investment cost
  • Longevity of ceramic
  • None maintenance rollers
  • 4 stainless seals each roll
  • Won’t catch or tear belting
  • Tapper and ball bearing combination
  • Unaffected by mechanical belt splicing
  • No maintenance required
  • Simplified frame
  • Even wear through rotation
  • Opposing 45 degree rolls for better belt tracking




What is required from the customer is the outside or inside dimension of the support channel beams, belt distance below the support beams, and belt width size for fabrication.When installed it is our recommendation that the ceramic belt wiper be installed with a pre-load of ¼” to ½” directly behind the discharge pulley or closest to the discharge pulley.
